An existing high-speed automatic door should have the entire sheet replaced when broken which causes inconvenience. KAD-3000 is an automatic door reducing such inconvenience and maintenance expenses thereof and having a function of sheets automatically recovered even after impact.

• Automatic self-recovery function: when a sheet is attached and detached due to impact of vehicles (forklift), an existing automatic door should be recovered artificially, but KAD-3000 is completely recovered automatically by raising and lowering the automatic door when the automatic door is closed (reducing risk of impact and anxiety).
• An aluminum bar (wind bar) at the center of sheet is not necessary, and we do our best for safety by using a flexible material (special rubber) in a bar installed at the lower part.
• The product endures strong wind pressure by holding the side part of door with a high-strength plastic ball.

• Hypoid geared motor



  • Manufacturer : Sumitomo
  • Country : JAPAN
  • Insulation clas : B CLASS
  • Features : Low noise and high-efficiency motor / ultra light size, high efficiency is achieved due to less sliding compared with worm gear

• Siemens motor



  • Manufacturer : SIEMENS
  • Manufacturing company: Germany
  • Worm decelerator applied
  • Providing various sizes and capacities
  • Low-noise and low-vibration

• Manual chain motor



  • Manufacturer : BLUETEM
  • Manufacturing country : Korea
  • Worm decelerator applied
  • Available of emergency opening and closing

• Controller (BAC-2200)



  • Controller for industrial automatic door
  • Available of variable inverter speed control
  • Applying Europe CE, reliable high functional controller
  • Maximizing electric power reduction effect, cost reduction by using single-phase power and easy installation
  • Using waterproof case

• Controller (BAC-2500)



  • Controller for industrial automatic door(Korean available)
  • Upgraded case design
  • Available of variable inverter speed control
  • Reliable high functional controller
  • Maximizing electric power reduction effect, cost reduction by using single-phase power and easy installation

• Sheet



  • Material : Poly belt
  • Structure : double weaving / flame retardant and UV coating
  • Thickness : 1T, 2T(invisible screen 3T)
  • Colors : Blue, orange, gray (Other colors and special specifications can be ordered)




• Frame



  • It is made of high-strength AL dual-press molding material with a graceful appearance. It is semi-permanent with excellent durability even in corrosive, humid environment or under strong impact.

• Infrared safety sensor (Photo Sensor)



  • Sunlight 50,000 Lux
  • Internal micro processor
  • Photo sensors are install on right and left to detect a person or other objects to keep the automatic door opening.

• Tooth



  • The sheet is separated from a rail when being impacted, and is automatically recovered by raising and lowering the door
  • Reducing maintenance expenses for breakage, service life shortening, sheet damages caused by impact
